Set up HLS live view

Written by Cedric Verstraeten Created Aug 19, 2026 Updated Aug 19, 2026

HLS live view carries video over ordinary authenticated HTTPS. It needs no browser-to-Agent media path, ICE negotiation or TURN relay, which makes it the most predictable Kerberos live transport across corporate firewalls, VPNs and mobile networks.

Kerberos uses CMAF/fMP4 packaging and enables low-latency HLS (LL-HLS) by default. An Agent creates short-lived media parts only while someone is watching, uploads them to Hub API, and the browser follows a rolling playlist with hls.js.

Understand the path

HLS separates control traffic from media traffic. The browser repeatedly requests a live session over MQTT. The Agent packages encoded camera frames into CMAF, uploads an init object and media parts to Hub API over HTTPS, then announces the ready session over MQTT. The browser fetches that session’s playlist and media from Hub API with its bearer token.

The Agent stops live uploads about eight seconds after the last viewer keepalive. With prewarming enabled, it keeps only a small encoded window in memory while idle and flushes it when the next viewer arrives; it does not continuously send idle video to Hub.

Before you start

You need:

• A self-hosted Hub whose API and frontend are available through HTTPS.
• A connected Agent with Hub URI, access key and private key configured.
• Live view enabled in the Agent camera configuration.
• MQTT connectivity between Hub frontend and Agent.
• Outbound HTTPS from the Agent to Hub API.
• An H.264 camera stream for reliable browser playback.

The Agent segmenter can package H.265, but browser HEVC support varies by operating system, browser and hardware. Use H.264 unless every target operator device has been validated with your exact stream.

Configure Hub

kerberoshub:
  frontend:
    features:
      liveview:
        liveStreamMode: "hls"
        hlsEnabled: "true"
        moqEnabled: "false"

helm repo add kerberos https://charts.kerberos.io
helm repo update
helm upgrade hub kerberos/hub \
  --namespace kerberos-hub \
  --values values.yaml
kubectl -n kerberos-hub rollout status deployment/hub-api
kubectl -n kerberos-hub rollout status deployment/hub-frontend

Configure the Agent

HLS uses the existing Hub identity rather than HLS-specific credentials. A containerized Agent needs the equivalent of:

env:
  - name: AGENT_HUB_URI
    value: "https://api.hub.example.com"
  - name: AGENT_HUB_KEY
    valueFrom:
      secretKeyRef:
        name: agent-hub
        key: access-key
  - name: AGENT_HUB_PRIVATE_KEY
    valueFrom:
      secretKeyRef:
        name: agent-hub
        key: private-key

Factory-managed Agents already receive these values from their assigned Hub account. Also confirm the Agent is online and live view is enabled for the camera; its HLS producer exits when either condition is false.

Keep the low-latency defaults

The current Agent enables both optimizations unless they are set to the exact string false:

No variables are required for the recommended setup. If your deployment templates prefer explicit intent, set both to true:

env:
  - name: AGENT_LIVE_HLS_LOW_LATENCY
    value: "true"
  - name: AGENT_LIVE_HLS_PREWARM
    value: "true"

Disable low latency only to diagnose a client or proxy that mishandles LL-HLS parts. Disable prewarming only when minimizing idle CPU is more important than startup speed.

Restart the Agent after changing its environment and confirm startup logs report both features as enabled:

kubectl -n <agent-namespace> rollout restart deployment/<agent-deployment>
kubectl -n <agent-namespace> rollout status deployment/<agent-deployment>
kubectl -n <agent-namespace> logs deployment/<agent-deployment> \
  | grep -i 'live HLS'

Expected messages include:

live HLS prewarm ENABLED
live HLS low-latency (LL-HLS) ENABLED

Configure the network

HLS is friendly to stateful firewalls because the camera site accepts no new inbound connection:

Allow long-lived WebSockets through load balancers and reverse proxies. Ensure proxies pass authorization headers and do not apply long cache lifetimes to /storage/live/; Hub owns the rolling playlist and short media TTL.

For a standard authenticated stream, the browser loads:

GET /storage/live/<device>/<session>/index.m3u8
GET /storage/live/<device>/<session>/<part-or-segment-name>
Authorization: Bearer <access-token>

Never expose these paths through an unauthenticated static file service. Hub verifies that the signed-in user owns the device before serving live media.

Verify the stream

1. Open Hub, choose a camera, select Live, then choose HLS if it is not already active.
2. Hover the live status indicator and watch the phases advance:

3. Open browser developer tools and filter the Network panel for m3u8, m4s or storage/live.
4. Confirm the playlist returns 200, contains #EXT-X-PART in LL-HLS mode, and subsequent media requests remain successful.
5. Follow Agent and Hub API logs while reconnecting:

kubectl -n <agent-namespace> logs deployment/<agent-deployment> \
  --follow | grep -i 'live HLS'
kubectl -n kerberos-hub logs deployment/hub-api \
  --follow | grep -i -E 'storage/live|live hls'

The Agent should log a prewarmed session, activate uploads for the viewer, and announce the session after its first part or segment lands. Closing the viewer should stop uploads after the keepalive timeout.

Verify quality selection

If the camera has both main and sub streams configured, change the HLS quality control between High and Low. Each change requests a fresh session because resolution and codec initialization belong to that session.

• High selects the camera main stream.
• Low selects the camera sub stream.
• Auto lets the Agent apply its configured stream-selection policy.

Use H.264 for both streams. A lower-resolution sub stream is useful on constrained uplinks because each active viewer causes the Agent to upload one selected live rendition to Hub.

Measure latency and load

LL-HLS targets approximately 1-2 seconds glass-to-glass under healthy conditions. Whole-segment HLS is normally around 4-6 seconds because the player buffers multiple approximately 2-second segments. Actual latency also includes the camera GOP, Agent upload, Hub response time and browser buffer.

When sizing the deployment, account for:

• One Agent-to-Hub upload per active camera session, not per browser.
• Hub-to-browser egress for every viewer.
• Short-lived live objects and playlist requests in Hub API.
• Camera bitrate and keyframe interval. Long GOPs slow un-prewarmed startup and recovery.

Troubleshoot common failures

If HLS works while WebRTC fails, the likely fault is ICE/TURN or direct UDP rather than camera capture. Continue with Set up WebRTC live view with TURN to add the lower-latency interactive path, or read Choose a live-stream transport: MoQ vs HLS vs WebRTC to compare the tradeoffs.
